Yamaha MT-10 2019 User Manual

Instrument and control functions
4-8
1
2
3
4
5
6
7
8
9
10
11
12
EAU79183
Multi-function meter unit
WARNING
EWA12423
Be sure to stop the vehicle before
making any setting changes to the
multi-function meter unit. Changing
settings while riding can distract the
operator and increase the risk of an
accident.
The multi-function meter unit is
equipped with the following:
 a speedometer
 a tachometer
 a clock
 a fuel meter
 a coolant/air temperature display
 an eco indicator
 a transmission gear display
 a drive mode display
 a TCS display
 a QS indicator
 a multi-function display
TIP
To switch the multi-function meter unit
between kilometers and miles, push
the “CLOCK” button and “RESET” but-
ton at the same time.
1. “CLOCK” button
2. “RESET” button
12
1. Transmission gear display
2. Clock
3. Tachometer
4. Coolant temperature display/air
temperature display
5. Speedometer
6. Fuel meter
7. Eco indicator “ECO”
8. Drive mode display
9. TCS display
10.QS indicator
11.Multi-function display
12 3 546
910 7811
B67-9-E4.book 8 ページ ２０１９年７月１９日 金曜日 午後４時２３分

Yamaha MT-10 2019 Specifications

General

Displacement	998 cc
Bore x Stroke	79.0 mm x 50.9 mm
Compression Ratio	12.0:1
Maximum Power	118.0 kW (160.4PS) @ 11, 500 rpm
Maximum Torque	111.0 Nm (11.3 kg-m) @ 9, 000 rpm
Fuel System	Fuel Injection
Ignition System	TCI
Transmission	6-speed
Final Drive	Chain
Front Suspension	Telescopic forks, Ø 43 mm
Rear Suspension	Swingarm, (link suspension)
Rear Brakes	Hydraulic single disc, Ø 220 mm
Front Tyre	120/70 ZR17 M/C (58W)
Rear Tyre	190/55 ZR17 M/C (75W)
Dimensions (L x W x H)	2, 095 mm x 800 mm x 1, 110 mm
Seat Height	825 mm
Wheelbase	1, 400 mm
Minimum Ground Clearance	130 mm
Wet Weight	210 kg
Fuel Tank Capacity	17 liters
Starter System	Electric
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Frame	Deltabox
Front Brakes	Dual 320mm hydraulic disc
