Yamaha MT-10 2019 User Manual

Instrument and control functions
4-27
1
2
3
4
5
6
7
8
9
10
11
12
EAU15152
Luggage strap holders
There is a luggage strap holder on each
passenger footrest.
EAU67050
EXUP system
This model is equipped with Yamaha’s
EXUP (EXhaust Ultimate Power valve)
system. This system boosts engine
power by means of a valve that controls
exhaust flow within the exhaust cham-
ber.
NOTICE
ECA15611
The EXUP system has been set and
extensively tested at the Yamaha
factory. Changing these settings
without sufficient technical knowl-
edge may result in poor perfor-
mance of or damage to the engine.
EAU49454
Auxiliary DC jack
A 12-V accessory connected to the
auxiliary DC jack can be used when the
main switch is on.
NOTICE
ECA15432
The accessory connected to the
auxiliary DC jack should not be used
with the engine turned off, and the
load must never exceed 12 W (1.0 A),
otherwise the fuse may blow or the
battery may discharge.
To use the auxiliary DC jack
1. Turn the main switch off.
2. Remove the auxiliary DC jack cap.
1. Luggage strap holder
1
1. Auxiliary DC jack cap
1
B67-9-E4.book 27 ページ ２０１９年７月１９日 金曜日 午後４時２３分

Yamaha MT-10 2019 Specifications

General

Displacement	998 cc
Bore x Stroke	79.0 mm x 50.9 mm
Compression Ratio	12.0:1
Maximum Power	118.0 kW (160.4PS) @ 11, 500 rpm
Maximum Torque	111.0 Nm (11.3 kg-m) @ 9, 000 rpm
Fuel System	Fuel Injection
Ignition System	TCI
Transmission	6-speed
Final Drive	Chain
Front Suspension	Telescopic forks, Ø 43 mm
Rear Suspension	Swingarm, (link suspension)
Rear Brakes	Hydraulic single disc, Ø 220 mm
Front Tyre	120/70 ZR17 M/C (58W)
Rear Tyre	190/55 ZR17 M/C (75W)
Dimensions (L x W x H)	2, 095 mm x 800 mm x 1, 110 mm
Seat Height	825 mm
Wheelbase	1, 400 mm
Minimum Ground Clearance	130 mm
Wet Weight	210 kg
Fuel Tank Capacity	17 liters
Starter System	Electric
Engine Type	Liquid-cooled, 4-stroke, DOHC, 4-valve
Frame	Deltabox
Front Brakes	Dual 320mm hydraulic disc
