Instrument and control functions
5-17
1
2
3
4
5
6
7
8
9
10
11
12
13
Traction control system
This model uses a variable traction
control system. For each setting level,
the farther the vehicle is leaned over,
the more traction control (system inter-
vention) is applied. There are 5 setting
levels available. Setting level 1 applies
the least system intervention, while set-
ting level 5 applies the most overall
traction control.
The traction control system can
only be turned off completely via
the main screen using the “MODE”
switch and MODE up “ ” switch.
See “Turning off the traction con-
trol system” on page 5-14.
When the traction control system
has been turned off; TCS, SCS
and LIF will be set to OFF and can-
not be adjusted. When the traction
control system is turned on again,
these related-traction control func-
tions will return to their previous
setting levels.
SCS
SCS can be set to OFF, 1, 2, and 3.
OFF turns the slide control system off,
setting level 1 provides the least sys-
tem intervention, and setting level 3
provides the most system intervention.
Quick shifter
The quick shifter is divided into QS
(upshift) and QS (downshift) sec-
tions. QS and QS are not linked
and can be independently turned on or
off.
OFF turns the respective upshift or
downshift function off, and the clutch le-
ver must then be used when shifting in
that direction.
1. PWR 1
2. PWR 2
3. PWR 3
4. PWR 4
5. Throttle valve opening
6. Throttle grip operation
1. System intervention
2. Lean angle
1. System intervention
2. Sideward slide
1
3
2
1
SCS
2
