Periodic maintenance and adjustment
8-11
1
2
3
4
5
6
7
8
9
10
11
12
13
4. If the engine oil is at or below the
minimum level mark, remove the
oil filler cap and add oil
5. Check the O-ring for damage, and
replace if necessary.
6. Install the engine oil filler cap.
To change the engine oil (and filter)
1. Start the engine, warm it up for
several minutes, and then turn it
off.
2. Place an oil pan under the engine
to collect the used oil.
3. Remove the engine oil filler cap,
the engine oil drain bolt and its
gasket to drain the oil from the
crankcase.
Skip steps 4–6 if the oil filter cartridge is
not being replaced.
4. Remove the oil filter cartridge with
an oil filter wrench.
1. Engine oil level check window
2. Maximum level mark
3. Minimum level mark
1. Engine oil filler cap
2. O-ring
1
2
1. Engine oil filler cap
1. Engine oil drain bolt
2. Gasket
1
2
B5Y-9-10-E0.book 11 ページ ２０２１年１２月１５日 水曜日 午後１時３０分
