Yamaha MT400 - Circuit Boards

12
MT400
to REC 1/2-CN504
to SUB 1/3-CN101
to MIX 3/3-CN110
to MIX 2/3-CN109
to SUB 2/3-CN107
to MIX 2/3-CN112
to MIX 2/3-CN108
to SUB 1/3-
CN102
CIRCUIT BOARDS
MIX-1/3 Circuit Board
Component side
MIX : MT400-3400
