ELECTRICAL PARTS
MT400
C413 Ceramic Capacitor UP050 10P SL J 50V 01
C414 Mylar Capacitor ECQB 0.01 J 50V 01
C415 Mylar Capacitor ECQB 1200P J 50V 01
C416 Ceramic Capacitor UP050 10P SL J 50V 01
C417 Electrolytic Cap. UVR1H 10 M 50V
C419 Electrolytic Cap. UVR1E 22 M 25V
C501 Electrolytic Cap. UVR1H 10 M 50V
C502 Ceramic Capacitor UP050 100P B K 50V 01
C503 Electrolytic Cap. UVR1E 22 M 25V
C504 Electrolytic Cap. UVR1H 10 M 50V
C505 Ceramic Capacitor UP050 15P SL J 50V 01
C506 Ceramic Capacitor UP050 15P SL J 50V 01
C507 Electrolytic Cap. UVR1E 22 M 25V
C508 Electrolytic Cap. UVR1H 10 M 50V
C509 Ceramic Capacitor UP050 100P B K 50V 01
C510 Electrolytic Cap. UVR1E 22 M 25V
C511 Electrolytic Cap. UVR1H 10 M 50V
C512 Electrolytic Cap. UVR1A 100 M 10V
C513 Electrolytic Cap. UVR1C 220 M 16V
C514 Mylar Capacitor ECQB 0.1 J 50V 01
C515 Electrolytic Cap. UVR1A 100 M 10V
C516 Electrolytic Cap. UVR1A 100 M 10V
-518 Electrolytic Cap. UVR1A 100 M 10V
C520 Ceramic Capacitor UP050 100P B K 50V 01
C601 Electrolytic Cap. UVR1H 10 M 50V
C602 Ceramic Capacitor UP050 100P B K 50V 01
C603 Electrolytic Cap. UVR1E 22 M 25V
C604 Electrolytic Cap. UVR1H 10 M 50V
C605 Ceramic Capacitor UP050 15P SL J 50V 01
C606 Ceramic Capacitor UP050 15P SL J 50V 01
C607 Electrolytic Cap. UVR1E 22 M 25V
C611 Electrolytic Cap. UVR1H 10 M 50V
C612 Electrolytic Cap. UVR1A 100 M 10V
C613 Electrolytic Cap. UVR1C 220 M 16V
C614 Mylar Capacitor ECQB 0.1 J 50V 01
CN101 Cable Holder 51048-1000 10P
CN101 Flat Cable 10P L70
CN102 Cable Holder 51048-0600 6P
CN102 Flat Cable 6P L70
CN103 Cable Holder 51048-0500 5P
CN103 Flat Cable 5P L90
CN104 Cable Holder 51048-0800 8P
CN104 Flat Cable 8P L130
CN105 Cable Holder 51048-0800 8P
CN105 Flat Cable 8P L300
CN106 Cable Holder 51048-0800 8P
CN106 Flat Cable 8P L100
CN107 Cable Holder 51048-0800 8P
CN107 Flat Cable 8P L150
CN108 Wire Trap 52147-1010 10P
CN109 Wire Trap 52147-0610 6P
CN110 Wire Trap 52147-0510 5P
CN111 Cable Holder 51048-0600 6P
CN111 Flat Cable 6P L70
CN112 Wire Trap 52147-0610 6P
IC101 IC NJM2068L-D OP AMP 01
IC102 IC NJM2068L-D OP AMP 01
IC103 IC NJM4558L OP AMP 03
-110 IC NJM4558L OP AMP 03
IC111 IC M5216L OP AMP 03
IC203 IC NJM4558L OP AMP 03
IC303 IC NJM4558L OP AMP 03
IC403 IC NJM4558L OP AMP 03
JK101 Phone Jack YKB21-5012G MIC/LINE INPUT 1
JK102 Phone Jack YKB21-5074G Input 1 INSERT I/O
JK103 Phone Jack YKB21-5012G STEREO INPUT 5L,6R,7L,8R
-106 Phone Jack YKB21-5012G
JK108 Phone Jack YKB21-5012G AUX SEND 1
JK109 Phone Jack YKB21-5012G AUX SEND 2
JK201 Phone Jack YKB21-5012G MIC/LINE INPUT 2
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
VF466600
UA654100
UA653120
VF466600
FX804270
FX804280
FX804270
VF466800
FX804280
FX804270
VG276200
VG276200
FX804280
FX804270
VF466800
FX804280
FX804270
FX804290
FX804300
UA655100
FX804290
FX804290
FX804290
VF466800
FX804270
VF466800
FX804280
FX804270
VG276200
VG276200
FX804280
FX804270
FX804290
FX804300
UA655100
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
XM356A00
XM356A00
IX614610
IX614610
XB419A00
IX614610
IX614610
IX614610
LX804900
LX804910
LX804900
LX804900
LX804900
LX804900
LX804900
ELECTRICAL PARTS MT400
Circuit Board MIX 3/3
Circuit Board MIX 2/3
Circuit Board MIX 1/3
Circuit Board REC 2/2
Circuit Board REC 1/2
Circuit Board SUB 3/3
Circuit Board SUB 2/3
Circuit Board SUB 1/3
Circuit Board MIX 3/3
Circuit Board MIX 2/3
Circuit Board MIX 1/3
1P Contact Assembly MT400-903
Jumper Wire 5mm
Jumper Wire 10mm
C101 Ceramic Capacitor UP050 470P B K 50V 01
C102 Electrolytic Cap. UVR1H 10 M 50V
C103 Electrolytic Cap. UVR1A 100 M 10V
C104 Ceramic Capacitor UP050 22P SL J 50V 01
C105 Electrolytic Cap. UVR1E 22 M 25V
C106 Electrolytic Cap. UVR1A 100 M 10V
-109 Electrolytic Cap. UVR1A 100 M 10V
C110 Electrolytic Cap. UVR1H 10 M 50V
C111 Mylar Capacitor ECQB 0.033 J 50V 01
C112 Mylar Capacitor ECQB 1000P J 50V 03
C113 Ceramic Capacitor UP050 10P SL J 50V 01
C114 Mylar Capacitor ECQB 0.01 J 50V 01
C115 Mylar Capacitor ECQB 1200P J 50V 01
C116 Ceramic Capacitor UP050 10P SL J 50V 01
C117 Electrolytic Cap. UVR1H 10 M 50V
C119 Electrolytic Cap. UVR1E 22 M 25V
C121 Ceramic Capacitor UP050 0.1 F Z 50V 01
C122 Ceramic Capacitor UP050 0.1 F Z 50V 01
C201 Ceramic Capacitor UP050 470P B K 50V 01
C202 Electrolytic Cap. UVR1H 10 M 50V
C203 Electrolytic Cap. UVR1A 100 M 10V
C204 Ceramic Capacitor UP050 22P SL J 50V 01
C205 Electrolytic Cap. UVR1E 22 M 25V
C210 Electrolytic Cap. UVR1H 10 M 50V
C211 Mylar Capacitor ECQB 0.033 J 50V 01
C212 Mylar Capacitor ECQB 1000P J 50V 03
C213 Ceramic Capacitor UP050 10P SL J 50V 01
C214 Mylar Capacitor ECQB 0.01 J 50V 01
C215 Mylar Capacitor ECQB 1200P J 50V 01
C217 Electrolytic Cap. UVR1H 10 M 50V
C219 Electrolytic Cap. UVR1E 22 M 25V
C301 Ceramic Capacitor UP050 470P B K 50V 01
C302 Electrolytic Cap. UVR1H 10 M 50V
C303 Electrolytic Cap. UVR1A 100 M 10V
C304 Ceramic Capacitor UP050 22P SL J 50V 01
C305 Electrolytic Cap. UVR1E 22 M 25V
C310 Electrolytic Cap. UVR1H 10 M 50V
C311 Mylar Capacitor ECQB 0.033 J 50V 01
C312 Mylar Capacitor ECQB 1000P J 50V 03
C313 Ceramic Capacitor UP050 10P SL J 50V 01
C314 Mylar Capacitor ECQB 0.01 J 50V 01
C315 Mylar Capacitor ECQB 1200P J 50V 01
C316 Ceramic Capacitor UP050 10P SL J 50V 01
C316 Ceramic Capacitor UP050 10P SL J 50V 01
C317 Electrolytic Cap. UVR1H 10 M 50V
C319 Electrolytic Cap. UVR1E 22 M 25V
C401 Ceramic Capacitor UP050 470P B K 50V 01
C402 Electrolytic Cap. UVR1H 10 M 50V
C403 Electrolytic Cap. UVR1A 100 M 10V
C404 Ceramic Capacitor UP050 22P SL J 50V 01
C405 Electrolytic Cap. UVR1E 22 M 25V
C410 Electrolytic Cap. UVR1H 10 M 50V
C411 Mylar Capacitor ECQB 0.033 J 50V 01
C412 Mylar Capacitor ECQB 1000P J 50V 03
NX820190
NX820200
NX820210
NX820140
NX820150
NX820160
NX820170
NX820180
NX820190
NX820200
NX820210
--
--
--
VF466900
FX804270
FX804290
VG276600
FX804280
FX804290
FX804290
FX804270
UA654330
UA653100
VF466600
UA654100
UA653120
VF466600
FX804270
FX804280
VI307100
VI307100
VF466900
FX804270
FX804290
VG276600
FX804280
FX804270
UA654330
UA653100
VF466600
UA654100
UA653120
FX804270
FX804280
VF466900
FX804270
FX804290
VG276600
FX804280
FX804270
UA654330
UA653100
VF466600
UA654100
UA653120
VF466600
VF466600
FX804270
FX804280
VF466900
FX804270
FX804290
VG276600
FX804280
FX804270
UA654330
UA653100
