Adjusting the rear brake light switch
The rear brake light switch, which is activated
by the brake pedal and brake lever, is proper-
ly adjusted when the brake light comes on just
before braking takes effect. If necessary, ad-
just the brake light switch as follows.
Turn the adjusting nut while holding the rear
brake light switch in place. To make the brake
light come on earlier, turn the adjusting nut in
direction
a
. To make the brake light come on
later, turn the adjusting nut in direction
b
.
1. Rear brake light switch
2. Rear brake light switch adjusting nut
EBU00741
Clutch lever free play adjustment
The clutch lever free play should be adjusted
to 5–10 mm (0.20–0.39 in).
1. Loosen the locknut at the clutch lever.
2. Turn the adjusting bolt at the clutch lever
in direction
a
to increase the free play or
in direction
b
to decrease the free play.
3. Tighten the locknut at the clutch lever.
N
TE:
If the specified free play cannot be obtained,
proceed with the following steps.
