Yamaha RAPTOR 700 User Manual

8-19
EBU08070
Panel removal and installation
The panel illustrated needs to be removed to
perform some of the maintenance described in
this chapter.
Refer to this section each time the panel has to
be removed or installed.
EBU10130
Panel A
To remove
Remove the bolts, and then take the panel off.
To install
Place the panel in the original position, and then
install the bolts.
1
1
2
2
1. Panel A
1. Panel A
1. Panel A
1. Panel A 2. Bolt (
×2)
1. Panel A 2. Boulon (×2)
1. Panel A 2. Perno (×2)
1S3-9-60 8 6/7/05 10:25 AM Page 8-19
