(See Fig. li.) (See Еі. .)
After unpacking, check that the following parts are . FRONT PANEL
provided. :
@ Display window
Φ Remote control transmitter
(DPRESET display
e Batteries Preset station indicator
Lights up to indicate the pressed preset station
@
Remote
control
cable
(6-pin)
|
button.
|
P1-P8/P9-P16 indicators |
e Remote control cable (mini-plug) Indicates the range (either P1-P8 or P9-P16) of
selectable preset station buttons.
AM
|
te
|
ә
оор
antenna
(2)STATION
FREQUENCY
display
Displays the band and frequency of the received
radio signal.
(3)SIGNAL QUALITY indicators
These indicators display the signal strength of the
tuned frequency in bar-graph form. 0 marks a poor
or no signal, while 100 indicates an excellent signal.
(4)INPUT indicator
Indicates the program source selected by the Input
selector.
(5) SURROUND indicator
Lights up while the surround processor in this unit
is being used.
(€ SLEEP indicator
This indicator illuminates beginning from the time
that the SLEEP key of the remote-control transmitter
is pressed and until the SLEEP mode is
automatically canceled one hour later.
(D STEREO indicator
When an FM stereo signal of sufficient strength is
received the STEREO indicator lights up.
(8 AUTO TUNING indicator
When the tuner is in automatic tuning mode, the
AUTO TUNING indicator lights.
- (8 MEMORY indicator
When the MEMORY button is pressed , the
MEMORY indicator blinks on and off.
Indoor FM antenna
e input selector (INPUT SELECTOR)
Used to select the program source to be heard. The
selected program source is indicated in the display.
@ Preset station buttons
Up to 16 station frequencies and reception modes can
be stored using the preset station button.
@ REAR LEVEL control
This control raise or lower the volume at REAR
SPEAKERS terminals.
@ SURROUND MODE selector
Used to select the surround mode according to the
source played.
SIMULATED SURROUND
Natural surround effects can be given to monaural
sources. While the front speakers reproduce ordinary
monaural sound, the rear speakers reproduce the
sound which has been distributed to the left and right
speakers by the comb filter.
OFF
Set to this position when listening to the normal 2-
channel stereo sound without reverberation effect. The
rear speaker signals are not output.
OO DOLBY SURROUND
Set to this position when playing the program source
having a “ DO DOLBY SURROUND” marking.
NATURAL SURROUND
Natural surround effects can be reproduced from
ordinary stereo sources, using, YAMAHA's original
surround processor circuit. |
* No sound is output from the rear speakers when
the played source is monaural.
@ CD DIRECT SWITCH (CD DIRECT)
This switch allows you to route the CD input signal
directly to the output stage bypassing the Input
- selector, Loudness, and Balance controls therefore
avoiding any "muddying" caused by the switch and
circuit routing to provide a pure sound.
