Yamaha SLIDER EW50 NAKED User Manual

PERIODIC MAINTENANCE AND MINOR REPAIR
6
1
2
ZAUM0153
1. Final transmission oil drain bolt
2. Final transmission oil filler cap
EAU04228
Final transmission oil
The final transmission case must be
checked for oil leakage before each
ride. If any leakage is found, have a
Yamaha dealer check and repair the
scooter. In addition, the final transmis-
sion oil must be changed as follows at
the intervals specified in the periodic
maintenance and lubrication chart.
1. Start the engine, warm it up by
riding the scooter for several mi-
nutes, and then stop the engine.
2. Place the scooter on the
centerstand.
3. Place an oil pan under the final
transmission case to collect the
used oil.
4. Remove the oil filler cap and drain
bolt to drain the oil from the final
transmission case.
5. Install the final transmission oil
drain bolt, and then tighten it to
the specified torque.
Tightening torque:
Final transmission oil drain bolt:
17 Nm (1.7 m•kgf)
6. Add the specified amount of the
recommended final transmission
oil, and then install and tighten the
oil filler cap.
Recommended final transmission oil:
See page 8-1.
Oil quantity:
0.11 L
EWA00062
•
Make sure that no foreign
material enters the final trans-
mission case.
•
Make sure that no oil gets on
7. Check the final transmission case
for oil leakage. If oil is leaking,
check for the cause.
6-6

Yamaha SLIDER EW50 NAKED Specifications

General

Displacement	49cc
Starter	Electric and kick
Front Suspension	Telescopic fork
Rear Suspension	Unit Swing
Max Torque	2.7 Nm @ 6, 000 rpm
Fuel System	Carburetor
Transmission	Automatic
Rear Brake	Drum
