4-134-12
STEERING CABLE INSPECTION
Be sure to check:
1) Check for smooth operation of the
wheel and steering nozzles.
2) Check for proper steering adjust-
ment. The nozzles should both point
straight back when the steering
wheel is centered.
If steering is stiff or misadjusted, ask
your Yamaha dealer to service it.
AIR FILTER
The air filter element should be
checked every 12 months or every 100
hours of operation.
To check the air filter:
1) Open the hood (see page 2-14).
2) Remove the air filter case cover
screws 1, slide the locks 2 to
open, and then remove the case
cover.
3) Remove the air filter element.
Check it for dirt and oil. Replace the
air filter every 2 years or every 200
hours of operation, or if it becomes
contaminated with dirt or oil.
MAINTENANCE & CARE 4
4 MAINTENANCE & CARE
