2-32
Outboard Rigging Guide - 2001 Dual Engine Tie Bar Kit Installation
DUAL ENGINE
TIE BAR KIT INSTALLATION
Please read and understand these instructions
completely before installation to avoid any possi-
ble injury to yourself or damage to the outboard or
the accessory.
Dual Engine Tie Bar Kit
(ABA-DUALT-IE-BR)
The tie bar is used to connect dual outboard
motors in order to achieve synchronized steering
and better engine performance.
Tie Bar Kit Application Chart
o = Optional
Sc = Standard in crate
NOTE: The LF115 cannot use this tie bar if a
Teleflex Center Mount Hydraulic Cylinder (5354)
is used.
MODEL
25HP~100HP
PART NUMBER ALL MODELS 115~250HP2-423 LF115~L250
ABA-DUALT-IE-BR
(279 ~ 914mm) (11.0in ~ 36.0in) ooSc
To Next Page
