Yamaha Thunderace YZF1000R User Manual

PERIODIC MAINTENANCE AND MINOR REPAIR
6-5
6
EAU01065
Removing and installing
cowlings
The cowlings shown above need to be
removed to perform some of the main-
tenance jobs described in this chapter.
Refer to this section each time a cowl-
ing needs to be removed and installed.
EAU00484
Cowling A
To remove the cowling
Remove the cowling screws, and then
pull the cowling off as shown.
To install the cowling
Place the cowling in the original posi-
tion, and then install the screws.
EAU03946
Cowling B
To remove the cowling
1. Remove the rider and passenger
seats. (See page 3-11 for rider
and passenger seat removal and
installation procedures.)
2. Remove the cowling screws, and
then pull the cowling off as shown.
1. Cowling A
2. Cowling B
3. Cowling C
1. Screw (× 13) 1. Screw (× 3)
E_4sv.book Page 5 Friday, November 10, 2000 3:03 PM

Yamaha Thunderace YZF1000R Specifications

General

Displacement	1002 cc
Compression Ratio	11.5:1
Final Drive	Chain
Frame	Aluminium Deltabox
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Engine Type	Liquid-cooled, 4-stroke, DOHC, 5-valve, inline-four
Bore x Stroke	75.5 mm x 56 mm
Maximum Power	145 hp @ 10, 000 rpm
Maximum Torque	108 Nm @ 8, 500 rpm
Ignition	Digital
Transmission	5-speed
Front Suspension	Telescopic forks, adjustable preload, compression and rebound damping
Rear Suspension	Swingarm, adjustable preload, compression and rebound damping
Front Brakes	2x 298mm discs 4 piston calipers
Rear Brakes	1x 245mm disc 2 piston caliper
Seat Height	810 mm
Fuel Capacity	19 liters
Dry Weight	198 kg
Ground Clearance	130 mm
