Yamaha Thunderace YZF1000R User Manual

8-1
8
EAU01038
8-
SPECIFICATIONS
Specifications
CS-01E
Model YZF1000R
Dimensions
Overall length 2,085 mm (except for CH, D, DK,
NL, S, SF)
2,170 mm (for CH, D, DK, NL, S,
SF)
Overall width 740 mm
Overall height 1,175 mm
Seat height 815 mm
Wheelbase 1,430 mm
Ground clearance 140 mm
Minimum turning radius 3,100 mm
Basic weight (with oil and full
fuel tank)
224 kg
Engine
Engine type Liquid-cooled 4-stroke, DOHC
Cylinder arrangement Forward-inclined parallel
4-cylinder
Displacement 1,002 cm
3
Bore × stroke 75.5 × 56.0 mm
Compression ratio 11.5:1
Starting system Electric starter
Lubrication system Wet sump
Engine oil
Ty p e
Recommended engine oil
classification API Service SE, SF, SG or
higher
Quantity
Without oil filter cartridge
replacement 3.0 L
With oil filter cartridge
replacement 3.2 L
Total amount (dry engine) 3.5 L
-20 -10 0
10
20 30
40
50 ˚C
SAE 10W-30
SAE 15W-40
SAE 20W-40
SAE 20W-50
SAE 10W-40
CAUTION:
Be sure to use motor oils that do not contain anti-fric-
tion modifiers. Passenger car motor oils (often labeled
“ENERGY CONSERVING II”) contain anti-friction addi-
tives which will cause clutch and/or starter clutch slip-
page, resulting in reduced component life and poor
engine performance.
E_4sv.book Page 1 Friday, November 10, 2000 3:03 PM

Yamaha Thunderace YZF1000R Specifications

General

Displacement	1002 cc
Compression Ratio	11.5:1
Final Drive	Chain
Frame	Aluminium Deltabox
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Engine Type	Liquid-cooled, 4-stroke, DOHC, 5-valve, inline-four
Bore x Stroke	75.5 mm x 56 mm
Maximum Power	145 hp @ 10, 000 rpm
Maximum Torque	108 Nm @ 8, 500 rpm
Ignition	Digital
Transmission	5-speed
Front Suspension	Telescopic forks, adjustable preload, compression and rebound damping
Rear Suspension	Swingarm, adjustable preload, compression and rebound damping
Front Brakes	2x 298mm discs 4 piston calipers
Rear Brakes	1x 245mm disc 2 piston caliper
Seat Height	810 mm
Fuel Capacity	19 liters
Dry Weight	198 kg
Ground Clearance	130 mm
