Yamaha Thundercat YZF600R User Manual

PERIODIC MAINTENANCE AND MINOR REPAIR
6-41
6
Engine overheating
EW000070
WARNING
@
Do not remove the radiator cap when the engine and radiator are hot. Scalding hot fluid and steam may be blown
out under pressure, which could cause serious injury. Open the radiator cap as follows. Wait until the engine has
cooled. Remove the radiator cap stopper by removing the screw. Place a thick rag like a towel over the radiator cap
and slowly rotate the cap counterclockwise to the detent. This procedure allows any residual pressure to escape.
When the hissing sound has stopped, press down on the cap while turning counterclockwise and remove it.
@
NOTE:
@
If it is difficult to get the recommended coolant, tap water can be temporarily used, provided that it is changed to the recom-
mended coolant as soon as possible.
@
Wait until the
engine has cooled.
Check the coolant level in the
reservoir tank and/or radiator.
Level is OK.
Level is low, check the
cooling system for leakage.
No
leakage.
Leakage.
Ask a Yamaha dealer to inspect
and repair the cooling system.
Add coolant. (See NOTE.)
Restart the engine. If the engine overheats again, ask a
Yamaha dealer to inspect and repair the cooling system.
E_4tv_Periodic.fm Page 41 Wednesday, September 1, 1999 11:12 AM

Yamaha Thundercat YZF600R Specifications

General

Bore x Stroke	62.0 mm x 49.6 mm
Compression Ratio	12.0:1
Ignition	Digital TCI
Transmission	6-speed
Final Drive	Chain
Front Suspension	Telescopic fork
Rear Tire	160/60-ZR17
Wheelbase	1, 440 mm
Length	2, 080 mm
Rear Suspension	Swingarm
Front Brakes	Dual disc
Rear Brakes	Single hydraulic disc
Dry Weight	187 kg
Maximum Power	100 hp @ 11, 500 rpm
Engine Type	599cc, liquid-cooled, 4-stroke, DOHC, inline-4
Front Tire	120/60-ZR17
Fuel Capacity	19 liters
