Yamaha TT600R User Manual

SWINGARM
4-80
CHAS
SWINGARM INSTALLATION
Perform “removal” operations in reverse order.
Note the following points.
1. Lubricate:
•
Bearings
•
Bushes
•
Thrust cover (inside)
•
Flange
•
Swingarm pivot shaft
•
Bolt (connecting rod)
•
Bolt (relay arm)
•
Bolt (shock absorber)
Lithium-base grease
2. Tighten:
Nut (relay arm-swingarm):
66 Nm (6.6 mkg)
Nut (relay arm - connecting rod):
52 Nm (5.2 mkg)
Bolt (chain case):
9 Nm (0.9 mkg)
Nut (swingarm pivot shaft):
90 Nm (9.0 mkg)
Bolt (chain support):
4 Nm (0.4 mkg)
Screw (chain case):
4 Nm (0.4 mkg)
Nut (relay arm-frame):
60 Nm (6.0 mkg)
Bolt (rear shock absorber):
59 Nm (5.9 mkg)
3. Install:
•
Rear wheel
Refer to “REAR WHEEL INSTALLATION”
section.

Yamaha TT600R Specifications

General

Displacement	595 cc
Compression Ratio	8.5:1
Fuel System	Carburetor
Ignition	CDI
Starting System	Kick
Transmission	5-speed
Front Suspension	Telescopic fork
Rear Suspension	Swingarm
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	90/90-21
Final Drive	Chain
Ground Clearance	315 mm
Engine Type	Single cylinder, 4-stroke
Cooling System	Air-cooled
