Dimensions:
Overall length:
2202 mm (86.7 in)
Overall width:
689 mm (27.1 in)
Overall height:
1175 mm (46.3 in)
Seat height:
820 mm (32.3 in)
Wheelbase:
1341 mm (52.8 in)
Ground clearance:
151 mm (5.94 in)
Minimum turning radius:
2900 mm (114.2 in)
Weight:
Curb weight:
124 kg (273 lb)
Engine:
Engine type:
Liquid cooled 2-stroke
Cylinder arrangement:
Single cylinder
Displacement:
49 cm
3
Bore x stroke:
40.3 x 39.0 mm (1.59 x 1.54 in)
Compression ratio:
11.50 : 1
Starting system:
Electric starter
Lubrication system:
Wet sump
Engine oil:
Type:
YAMALUBE 2S or 2-stroke engine oil
(JASO FC grade) or (ISO EG-C or EG-D
grade)
Engine oil quantity:
Quantity:
1.40 L (1.48 US qt, 1.23 Imp.qt)
Transmission oil:
Transmission oil change quantity:
0.75 L (0.79 US qt, 0.66 Im.qt)
Type:
SAE10W-30 type SE motor oil
Cooling system:
Coolant reservoir capacity (up to the maxi-
mum level mark):
0.29 L (0.31 US qt, 0.26 Imp.qt)
Radiator capacity (including all routes):
0.70 L (0.74 US qt, 0.62 Imp.qt)
Air filter:
Air filter element:
Wet element
Fuel:
Recommended fuel:
Premium unleaded gasoline only
Fuel tank capacity:
13.8 L (3.65 US gal, 3.04 Imp.gal)
Fuel reserve amount:
2.2 L (0.58 US gal, 0.48 Imp.gal)
Carburetor:
Manufacturer:
DELL’ORTO
Type x quantity:
PHBN 16 / DELL’ORTO x1
Spark plug(s):
Manufacturer/model:
NGK / BR9 ES
Spark plug gap:
0.6–0.7 mm (0.024–0.028 in)
Clutch type:
Wet, multiple-disc
Transmission:
Primary reduction ratio:
71/20 (3.55)
Secondary reduction ratio:
60/11 (5.45)
Final drive:
Chain
Transmission type:
Constant mesh 6-speed
Operation:
Left foot operation
Gear ratio:
1st:
36/12 (3.00)
2nd:
33/16 (2.062)
3rd:
29/19 (1.526)
4th:
32/24 (1.227)
5th:
25/24 (1.041)
6th:
24/25 (0.960)
Chassis:
Frame type:
Double cradle
SPECIFICATIONS
8-1
8
