3-6
EAU03447
Fuel tank cap
To remove the fuel tank cap
Slide the lock cover open, insert the
key into the lock, and then turn it 1/4
turn clockwise. The lock will be
released and the fuel tank cap can be
removed.
EW000024
w
Make sure that the fuel tank cap is
properly installed before riding.
INSTRUMENT AND CONTROL FUNCTIONS
3
1. Fuel tank cap lock cover
a. Unlock.
To install the fuel tank cap
1. Insert the fuel tank cap into the
tank opening with the key insert-
ed in the lock and with the marks
on the cap and tank aligned.
2. Turn the key counterclockwise to
the original position, remove it,
and then close the lock cover.
NOTE:
The fuel tank cap cannot be installed
unless the key is in the lock. In addi-
tion, the key cannot be removed if the
cap is not properly installed and
locked.
