Yamaha WOLVERINE YFM350FXS User Manual

8-19
EBU01111
Spark arrester cleaning
Be sure the exhaust pipe and muffler are cool
before cleaning the spark arrester.
1. Remove the bolt.
2. Remove the tailpipe by pulling it out of
the muffler.
1. Bolt
3. Tap the tailpipe lightly, and then use a
wire brush to remove any carbon depos-
its from the spark arrester portion of the
tailpipe.
4. Insert the tailpipe into the muffler and
align the bolt holes.
1. Tailpipe 2. Spark arrester
5. Install and tighten the bolt.
