Yamaha Wolverine YXE700E - STEERING SYSTEM

STEERING SYSTEM
4-47
EBS20029
STEERING SYSTEM
Removing the steering assembly
* Apply MOLYKOTE® EM-30L GREASE
Order Job/Parts to remove
Q
’ty
Remarks
Instrument panel assembly
Refer to “GENERAL CHASSIS (7)” on page
4-13.
1 Steering joint bolt 2
2 Steering column 1 Except for EPS models
3 EPS motor coupler 1
Disconnect.
For EPS models
4 EPS torque sensor coupler 1
Disconnect.
For EPS models
5 EPS unit 1 For EPS models
6 Steering joint 1
New
New
New
New
New
LS
LS
*
*
40 Nm (4.0 m
•
kgf, 29 ft
•
Ibf)
T
.R.
40 Nm (4.0 m
•
kgf, 29 ft
•
Ibf)
T
.R.
21 Nm (2.1 m
•
kgf, 15 ft
•
Ibf)
T
.R.
33 Nm (3.3 m
•
kgf, 24 ft
•
Ibf)
T
.R.
33 Nm (3.3 m
•
kgf, 24 ft
•
Ibf)
T
.R.
39 Nm (3.9 m
•
kgf, 28 ft
•
Ibf)
T
.R.
48 Nm (4.8 m
•
kgf, 35 ft
•
Ibf)
T
.R.
55 Nm (5.5 m
•
kgf, 40 ft
•
Ibf)
T
.R.
55 Nm (5.5 m
•
kgf, 40 ft
•
Ibf)
T
.R.
4
3
5
2
(4)
(4)
6
1
1
(4)
