1. Rear brake lever (page 3-12)
2. Left handlebar switches (page 3-10)
3. Speedometer (page 3-5)
4. Multi-function display (page 3-6)
5. Tachometer (page 3-6)
6. Right handlebar switches (page 3-10)
7. Front brake lever (page 3-11)
8. Throttle grip (page 6-20)
9. Front storage compartment B (page 3-16)
10.Main switch/steering lock (page 3-2)
11.Coolant level check window (page 6-16)
12.Front storage compartment A (page 3-16)
U1SDE1E0.book Page 3 Monday, September 23, 2013 3:55 PM
