Yamaha XP560D - Description

Description
2-1
2
EAU10411
Left view
1 2 3
4569 8 7
1. Fuses (page 8-31)
2. Battery (page 8-30)
3. Fuel tank cap (page 5-20)
4. Engine oil filler cap (page 8-12)
5. Sidestand (page 5-29)
6. Engine oil drain bolt (page 8-12)
7. Engine oil level check window (page 8-12)
8. Oil filter cartridge (page 8-12)
9. Coolant level check window (page 8-15)
