Yamaha XP560D - Controls and Instruments

Description
2-3
2
EAU10431
Controls and instruments
1 2 3 4 5 6 7 8 9
10,11
1212
1. Rear brake lever (page 5-18)
2. Left handlebar switches (page 5-1)
3. Rear brake lock lever (page 5-18)
4. Speedometer (page 5-4)
5. Multi-function display (page 5-5)
6. Tachometer (page 5-5)
7. Right handlebar switches (page 5-1)
8. Front brake lever (page 5-18)
9. Throttle grip (page 8-18)
10.Front storage compartment (page 5-23)
11.Auxiliary DC jack (page 5-28)
12.Smart key system switches (page 3-1)
