Periodic maintenance and adjustment
7-10
1
2
3
4
5
6
7
8
9
10
11
12
minimum level mark, remove the
oil filler cap and add oil.
5. Check the engine oil filler cap
O-ring. Replace if damaged.
6. Install the engine oil filler cap.
To change the engine oil (and filter)
1. Start the engine and allow it to idle
for a few minutes to warm up the
oil, and then stop the engine.
2. Place an oil pan under the engine
to collect the used oil.
3. Remove the engine oil filler cap,
and then the engine oil drain bolt
and gasket.
TIP
Skip steps 4–6 if the oil filter cartridge is
not being replaced.
4. Remove the oil filter cartridge with
an oil filter wrench.
TIP
An oil filter wrench is available at a
Yamaha dealer.
5. Apply a thin coat of clean engine
oil to the O-ring of the new oil filter
cartridge.
1. Engine oil filler cap
2. O-ring
2
1
1. Engine oil drain bolt
2. Gasket
21
1. Oil filter wrench
2. Oil filter cartridge
21
