Yamaha XT660R Service Manual

8 - 28
– +
ELEC
CHARGING SYSTEM
EAS00773
CHARGING SYSTEM
CIRCUIT DIAGRAM
ON
OFF
P
R/W
RR
L/W
B
B
WW
W
WW
W
G/WL/YGy G/W
L/B
R
B
R/B
R/W
Lg Y/L
R/G
B2 B
Y/LG/L
R/W
BBBR/G
WWW
BR
Br/R
Br/R
R
Br/L
R
Br/L
5
2
1
3
4
z
0 A B
6
7
8
9
Gy
L
R
Br/L
Br/R
G/W
R R
R R
R
B B
B B
B
R
W
R/G
R R R
Br
R/G
Br
R/W
L/W
G/L
R/W
BB
Y/L
B
W W
W W W
R
B
Sb
2 A.C. magneto 5 Rectifier/regulator 6 Battery 7 Main fuse

Yamaha XT660R Specifications

General

Displacement	660cc
Bore x Stroke	100.0 mm x 84.0 mm
Compression Ratio	10.0:1
Fuel System	Electronic Fuel Injection
Ignition System	TCI
Starter System	Electric
Transmission	5-speed
Final Drive	Chain
Rear Suspension	Swingarm
Front Tire	90/90-21
Rear Tire	130/80-17
Length	2, 240 mm
Width	865 mm
Height	1, 230 mm
Seat Height	865 mm
Wet Weight	181 kg
Fuel Capacity	15 liters
Lubrication System	Dry sump
Engine Type	Liquid-cooled, 4-stroke, SOHC, 4-valve
Front Suspension	Telescopic fork
Front Brake	Single disc, 298 mm
Rear Brake	Single disc, 245 mm
Maximum Power	35 kW (48 PS) @ 6, 000 rpm
Maximum Torque	58 Nm @ 5, 250 rpm
