8 - 22
– +
ELEC
STARTER MOTOR
EBS01061
STARTER MOTOR
2
3
4
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
New
New
New
T
R
.
.
18 Nm (1.8 m
•
kg, 13 ft
•
Ib)
T
R
.
.
20 Nm (2.0 m
•
kg, 14 ft
•
Ib)
1
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
Order Job/Part Q’ty Remarks
Removing the starter motor
Remove the parts in the order listed.
Exhaust pipe Refer to “ENGINE REMOVAL” in
chapter 4.
1 Parking brake cable holder 1
2 Oil delivery pipe 1 1
3 Starter motor lead 1 Disconnect.
4 Starter motor 1
For installation, reverse the removal pro-
cedure.
