8-39
1. Locknut 2. Adjusting nut
7. Turn the adjusting nut in direction a to
increase the free play or in direction b to
decrease the free play.
8. Tighten the locknut.
9. Reinstall the console.
10. Reinstall the seats.
EVU00880
Brake light switch adjustment
The brake light switch, which is activated by
the brake pedal, is properly adjusted when the
brake light comes on just before braking takes
effect. If necessary, adjust the brake light
switch as follows.
1. Open the hood. (See pages 8-7–8-8 for
hood opening and closing procedures.)
2. Turn the adjusting nut while holding the
brake light switch in place. To make the
brake light come on earlier, turn the ad-
justing nut in direction a. To make the
brake light come on later, turn the adjust-
ing nut in direction b.
3. Close the hood.
a
b
1
2
EE.book Page 39 Thursday, September 6, 2007 4:28 PM
