8-59
5B410024
Troubleshooting charts
Starting problems or poor engine performance
1. Fuel
Check if there is fuel
in the fuel tank.
There is fuel.
Restart the engine.
No fuel.
Supply fuel.
2. Compression
Use the electric
starter to see if
there is compression.
There is compression.
Compression normal.
No compression.
Ask a Yamaha dealer to
inspect.
3. Ignition
Remove the
spark plug and
check the electrodes.
Wet
Wipe clean with dry cloth.
Dry
Attach spark plug cap and
ground to chassis.
Use the
electric starter.
Spark is good.
Ignition system is
normal.
Spark is weak.
Adjust the spark plug gap
or replace the spark plug.
No spark.
Ask a Yamaha dealer to
inspect.
4. Battery
Use the electric starter.
Engine turns over
quickly.
Battery is good.
Engine turns over
slowly.
Check the connections,
recharge.
Check the compression.
EE.book Page 59 Thursday, September 6, 2007 4:28 PM
To Next Page
