THERMOSTAT
6-7
EAS26440
THERMOSTAT
Removing the thermostat
Order Job/Parts to remove Q’ty Remarks
Air filter case Refer to “AIR FILTER CASE” on page 7-5.
Canister (for California only) Refer to “THROTTLE BODIES” on page 7-8.
Coolant
Drain.
Refer to “CHANGING THE COOLANT” on
page 3-19.
1 Coolant temperature sensor coupler 1 Disconnect.
2 Thermostat outlet hose 1
3 Thermostat cover 1
4 Thermostat 1
For installation, reverse the removal proce-
dure.
T
R
.
.
12 Nm (1.2 m
•
kg, 8.7 ft
•
Ib)
3
4
2
1
To Next Page
