HANDLEBARS
4-40
EAS22850
HANDLEBARS
Removing the handlebars
Order Job/Parts to remove Q’ty Remarks
Left side panel/Left upper side cowling
Refer to “GENERAL CHASSIS” on page
4-1.
Fuel tank Refer to “FUEL TANK” on page 7-1.
Air filter case Refer to “AIR FILTER CASE” on page 7-5.
Canister (for California only) Refer to “THROTTLE BODIES” on page 7-8.
Air induction system cover
Refer to “AIR INDUCTION SYSTEM” on
page 7-15.
1 Left grip end 1
2 Handlebar grip 1
3 Clutch switch connector 2 Disconnect.
4 Left handlebar switch 1
5 Clutch cable 1 Disconnect.
6 Clutch lever assembly 1
7 Right grip end 1
8 Throttle cable housing 2
9 Throttle cable 2 Disconnect.
10 Throttle grip 1
T
R
.
.
32 Nm (3.2 m
•
kg, 23 ft
•
Ib)
LS
T
R
.
.
115 Nm (11.5 m
•
kg, 85 ft
•
lb)
T
R
.
.
13 Nm (1.3 m
•
kg, 9.4 ft
•
Ib)
LS
T
R
.
.
26 Nm (2.6 m
•
kg, 19 ft
•
Ib)
T
R
.
.
5 Nm (0.5 m
•
kg, 3.6 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
11 Nm (1.1 m
•
kg, 8.0 ft
•
Ib)
T
R
.
.
13 Nm (1.3 m
•
kg, 9.4 ft
•
Ib)
5
17
15
22
20
23
16
16
15
2
3
1
18
19
20
21
4
6
7
8
12
12
13
11
10
14
9
9
24
22
8
LS
