ELECTRICAL SPECIFICATIONS
2-13
EAS20310
ELECTRICAL SPECIFICATIONS
Voltage
System voltage 12 V
Ignition system
Ignition system Transistorized coil ignition (digital)
Advancer type Throttle position sensor and electrical
Ignition timing (B.T.D.C.) 10.0°/1300 r/min
Engine control unit
Model/manufacturer TBDF24/DENSO
Ignition coil
Model/manufacturer F6T558/MITSUBISHI
Minimum ignition spark gap 6.0 mm (0.24 in)
Primary coil resistance 1.19–1.61 Ω
Secondary coil resistance 8.5–11.5 kΩ
AC magneto
Model/manufacturer LMX62/DENSO
Standard output 14.0 V 420 W 5000 r/min
Stator coil resistance 0.12–0.18 Ω at 20 °C (68 °F)
Rectifier/regulator
Regulator type Semi conductor-short circuit
Model/manufacturer SH678–11/SHINDENGEN
Regulated voltage (DC) 14.1–14.9 V
Rectifier capacity 22.0 A
Battery
Model YTZ10S
Voltage, capacity 12 V, 8.6 Ah
Manufacturer GS YUASA
Ten hour rate amperage 0.86 A
Headlight
Bulb type Halogen bulb
Bulb voltage, wattage × quantity
Headlight 12 V, 55.0 W × 2
Auxiliary light 12 V, 5.0 W × 1
Tail/brake light LED
Front turn signal/position light 12 V, 21 W/5.0 W × 2
Rear turn signal light 12 V, 21.0 W × 2
License plate light 12 V, 5.0 W × 1
Meter lighting LED
Indicator light
Neutral indicator light LED
Turn signal indicator light LED
Oil level warning light LED
