TRANSMISSION
5-71
EAS26240
TRANSMISSION
Removing the transmission, shift drum assembly, and shift forks
Order Job/Parts to remove Q’ty Remarks
Crankcase
Separate.
Refer to “CRANKCASE” on page 5-55.
1 Drive axle assembly 1
2 Circlip 1
3 Oil seal 1
4 Bearing 1
5 Shift drum retainer 2
6Spring 2
7 Shift fork guide bar 2
8 Shift fork-L 1
9 Shift fork-R 1
10 Shift drum assembly 1
11 Shift fork-C 1
12 Main axle assembly 1
13 Oil pipe 1
14 Bearing 1
E
E
E
E
12
11
7
13
5
6
7
6
10
5
4
9
8
1
2
3
15
14
LT
LT
E
E
LT
E
T
R
.
.
12 Nm (1.2 m
•
kg, 8.7 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
E
New
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
(3)
New
LS
LS
