CHASSIS SPECIFICATIONS
2-11
Brake disc thickness limit 4.0 mm (0.16 in)
Brake disc deflection limit 0.10 mm (0.0039 in)
Brake pad lining thickness (inner) 4.5 mm (0.18 in)
Limit 0.5 mm (0.02 in)
Brake pad lining thickness (outer) 4.5 mm (0.18 in)
Limit 0.5 mm (0.02 in)
Master cylinder inside diameter 16.00 mm (0.63 in)
Caliper cylinder inside diameter 30.23 mm × 1 (1.19 in × 1)
Caliper cylinder inside diameter 27.00 mm × 1 (1.06 in × 1)
Recommended fluid DOT 4
Rear brake
Type Single disc brake
Operation Right foot operation
Rear disc brake
Disc outside diameter × thickness 220.0 × 5.0 mm (8.66 × 0.20 in)
Brake disc thickness limit 4.5 mm (0.18 in)
Brake disc deflection limit 0.15 mm (0.0059 in)
Brake pad lining thickness (inner) 6.0 mm (0.24 in)
Limit 1.0 mm (0.04 in)
Brake pad lining thickness (outer) 6.0 mm (0.24 in)
Limit 1.0 mm (0.04 in)
Master cylinder inside diameter 12.7 mm (0.50 in)
Caliper cylinder inside diameter 38.18 mm (1.50 in)
Recommended fluid DOT 4
Steering
Steering head tension 200–500 g
Steering bearing type Angular bearing
Lock to lock angle (left) 25.0°
Lock to lock angle (right) 25.0°
Front suspension
Type Telescopic fork
Spring/shock absorber type Coil spring/oil damper
Front fork travel 120.0 mm (4.72 in)
Fork spring free length 247.0 mm (9.72 in)
Limit 242.1 mm (9.53 in)
Collar length 80.0 mm (3.15 in)
Installed length 240.0 mm (9.45 in)
Spring rate K1 8.80 N/mm (50.25 lb/in) (0.90 kgf/mm)
Spring stroke K1 0.0–120.0 mm (0.00–4.72 in)
Inner tube outer diameter 41.0 mm (1.61 in)
Inner tube bending limit 0.2 mm (0.01 in)
Optional spring available No
Recommended oil Ohlins R & T43 (ACC-RT43F-00-00)
Quantity 465.0 cm³ (15.72 US oz) (16.37 Imp.oz)
Level 108.0 mm (4.25 in)
Rear suspension
Type Swingarm (link suspension)
Spring/shock absorber type Coil spring/gas-oil damper
Rear shock absorber assembly travel 60.0 mm (2.36 in)
