Yamatake SDC40B Series User Manual

Digital Controller SIO Driver
GP-Pro EX Device/PLC Connection Manual
133
8D)
• 1:1 Connection
• 1:n Connection
CA4-ADPONL-01
Display
Signal name
RDB
7
RDA
2
SDB
8
9
TERMTX
SDA
FG
3
TERMRX1
SG
5
D-Sub 9 pin (plug)
Pin
Shell
Shield
Terminal block
Controller
Signal name
DA
DB
SG
Terminal
resistance
150Ω ±5%
(more than
1/2W)
Terminal
resistance
150Ω ±5%
(more than
1/2W)
User-created cable
CA4-ADPONL-01
Display
Signal name
RDB
7
RDA
2
SDB
8
9
TERMTX
SDA
FG
3
TERMRX1
SG
5
D-Sub 9 pin (plug)
Pin
Shell
Shield
Terminal block
Controller
Signal name
DA
DB
SG
Shield
Terminal block
Controller
Signal name
DA
DB
SG
Terminal
resistance
150Ω ±5%
(more than
1/2W)
Terminal
resistance
150Ω ±5%
(more than
1/2W)
User-created cable
