EF393T OM
28
OTHERS
Seat adjust lever
It adjusts the operator’s seat position in 5 steps backward
or forward.
Raise the lever and slide forward or backward to desired
position. Lower the lever to latch the seat.
(A) Seat adjust lever
Seat belt
WARNING
Always fasten seat belt while operating the tractor with
the Roll-over Protective Structure (ROPS).
Do not use the seat belt if the tractor does not have the
ROPS.
(A) Seat belt
(B) PRESS button
Fasten the seat belt properly without twisting. Adjust the
belt length to operator figure.
Press “PRESS” button on the buckle to unfasten seat belt.
Opening bonnet
(1) Raise the lever to open bonnet. The bonnet goes up
and is hold with gas damper.
(A) Bonnet open lever
(B) Gas damper
