EF393T OM
69
SPECIFICATIONS
Model
EF393T
Engine
Make Yanmar
Model 3TNV88
Type Direct injection, Water cooled, diesel
Output SAE Gross (ps) 39.0
Rated RPM (rpm) 2800
No. of cylinders 3
Displacement (cc) 1,642 cc
Fuel tank (lit.) 38
Dimension
Overall length (mm) 2940
Overall width (mm) 1430
Overall height (steering wheel) (mm) 1950 (1400)
Tread
Front (mm) 1065
Rear (mm) 1120
Wheelbase (mm) 1650
Ground clearance (mm) 320
Weight (kg) 1090
Tire size
Front 8 - 16
Rear 12.4 - 24
Steering Hydrostatic power steering
Brake Wet multi-disc type
Clutch Dry single
Transmission
No. of shifting gears 8 forward and 8 reverse (constant mesh)
Reverser Synchro-mesh
Travel speed
Forward (km/hr) 1.90 – 21.1
Reverse (km/hr) 1.84 – 21.9
Turning radius (with brake) (m) 2.4
PTO
Gear 1 584 rpm (at engine speed: 2800rpm)
Gear 2 836 rpm (at engine speed: 2800rpm)
Hydraulic
system
Type Position control
Hitch 3-point hitch
Category Category 1
Max. lifting capacity (at lower link end) (kg) 925
Hydraulic pump capacity (lit./min) 20.2
Note:
All technical data, measurement and weight are approximate, and the manufacturer has the right to make
alteration without prior notice.
