2
WARNING! If any parts are damaged or missing, do not operate this tool until the
missing parts are replaced. Failure to heed this warning could result in serious
personal injury.
NOTE! Always recycle the packaging in accordance with local recycling schemes.
Parts List
As shown in Fig 1-4
1. Rear handle
2. Lock-off button
3. On/off trigger switch
4. Oil tank cap
5. Oil tank watching window
6. Front handle
7. Hand guard (chain brake actuating lever)
8. Chain blade
9. Saw rail
10. SDS tension knob
11. Clutch cover
12. Clamp knob
13. Tension pin
Check the delivery parts (Fig 5)
Battery pack and charger are sold separately.
Carefully remove the machine from its packaging and check as the following parts are
complete:
14. Locking pin
15. Sprocket
16. Battery pack (sold with AL GC2A only)
17. Battery pack release button
18. Power indicator button
19. Power indicator
20. Charger (sold with AL G40A only)
21. Green /Red led
22. Electric contacts
23. Plug
24. Gripping teeth
25. Catcher
Fig 5
E
C
B
D
G
F
A
A. Motor head
B. Saw rail
C. Saw blade
D. Blade cover
E. Charger (sold with AL G40A
only)
F. Battery pack (sold with AL
GC2A only)
G. Manual
DESCRIPTION OF PRODUCT PARTS
