26
If you want to install the panel to your balcony, we strongly our universal mounting system,
Model number AX SPSU1-EU, FMS 2024, which is sold separately. Please contact On-line
shop for this mounting material.
Suitable Balconies
Before unpacking, please verify that your balcony is compatible with the desired
mounting system!
The hand rail itself and its connection to the building must be capable and approved to carry
the added weight. This must include the wind force and snow load.
Please check the technical specifications for the maximum suitable wind zone and snow load
zone, and verify the local conditions with your local authorities to ensure compliance.
For the installation, please refer to the manual included with your mounting system. We
recommend attaching the inverter to the solar panel.
If the circuit breaker is added at the AC side, the circuit breaker with the rated current
of 10A is recommended.
Required Tools
A. 6 mm Hex key
B. 10 mm & 13 mm wrench
Step 1: Attach the inverter to solar panel
The solar panel's frame has holes for mounting the inverter. Find a suitable position,
taking into account the mounting system and DC cable length.
Refer to drawing (C) for the correct order of washers. Guide the screw. Tighten firmly.
Step 2: Electrical connections
Lay all cables in a way that they are free from tension and do not rub against sharp
edges. Do not kink the cables. Connect the solar panel to the inverter. Fully insert the
plugs to ensure the connection is permanently watertight.
Connect the matching plug of the AC cable to the inverter. Ensure the plug is locked in
position to ensure it is permanently watertight.
Guide the AC cable towards your socket.
Congratulations, the installation is complete.
The inverter and WLAN module will take a few seconds to boot up. Please follow the
respective installation guide on how to access the inverter.
INSTALLATION
B
D
C
