Yard force YF22-2N1 - Tying Down the Bowden Cable; Installing the Side Discharge Chute

10
Hotline: 1-866-902-9690
4. Place the upper handle in position over the lower handle, keeping the engine on/off control bar facing
up.
5. Secure the upper handle to the lower handle using the the handle knob and bolt (supplied) see Fig. 4.
TYING DOWN THE BOWDEN CABLE
As shown in Fig. 5
Attach the bowden cable to the handle with the cord clip (supplied).
INSTALLLING THE SIDE DISCHARGE CHUTE
As shown in Fig. 6
1. Lift the side discharge cover with one hand and hook in the side discharge chute with the other hand.
2. Release the side discharge cover to secure the chute in position.
ASSEMBLY
Bolt
Knob
Fig. 4
Fig.5
clip
Fig.6
side discharge
cover
side discharge
chute
