15
Hotline: 1-866-902-9690
4. Once the engine is running, put the starter rope into the rope guide (see Fig. 14).
TO STOP THE ENGINE
As shown in Fig. 15
Release the Engine On/Off Control Bar. It will return to its initial position and the engine will automatically
switch off.
TO CLEAN A FLOODED ENGINE
NOTE: If the engine won’t start after you have pulled the engine start rope several times, the engine
may be flooded with excess fuel. Use following procedure to clear and start a flooded engine.
1. Release the Engine On/Off Control Bar to stop engine.
2. Remove the spark plug, dry it, and then re-install it.
(1) Remove the spark plug cover (see Fig. 16).
Fig. 16
OPERATION
Fig.14
Fig.15
To Next Page
