16
Hotline: 1-866-902-9690
4. Once the engine is running, put the starter rope into the rope guide (see Fig. 15).
Fig. 15
TO STOP THE ENGINE
As shown in Fig. 16
Fig. 16
Release the Engine On/Off Control Bar. It will return to its initial position and the engine will automatically
switch off.
DRIVE CONTROL
As shown in Fig. 17
Fig. 17
1. Self-propelling is controlled by holding the engine on/off control bar down to the handle and push the
self-propelling bar to the handle.
2. To stop forward motion without stopping the engine, release the self-propelled drive control bar while still
holding the engine on/off control bar down against the handle to continue mowing without self-propel
drive activated.
NOTE: After releasing the self-propelling bar, if the mower will not roll backwards, push the mower
forward slightly to disengage the drive wheels.
OPERATION
