18
OPERATION
TO SET THE MOWER CUTTING HEIGHT
IMPORTANT NOTE: MAKE SURE ENGINE AND BLADE ARE STOPPED.
Adjust the cutting height to suit your requirements. The middle position is suitable for most lawns. Raise the
mower for high cut and lower the mower for low cut.
NOTE: For shipping purposes the height adjustment position may not be adjusted to the cutting position.
Before operating the mower adjust cutting height to the normal cutting position.
SINGLE POINT HEIGHT ADJUSTMENT(Fig. 15)
All four wheels are adjusted by a single lever.
1. Pull height adjuster toward wheel.
2. To raise the mower, move the lever backward to desired height position. To lower the mower, move the
lever toward the front.
DRIVE CONTROL(Fig. 16)
1. Self-propelling is controlled by holding the operator presence control bar down to the handle and
pulling the drive control lever(s) rearward to the handle. This machine is equipped with variable speed
system. The further toward the handle the lever is pulled, the faster the machine will travel.
2. To stop forward motion without stopping the engine, release the drive control lever(s) only. Hold the
operator presence control bar down against the handle to continue mowing without self-propelling.
Fig. 14
Fig. 15
