Yard Machines 30 User Manual

12
Model Series 030
Ref.
No.
Part No. Part Description
1 710-0779A Tap Scr. #10 x 1/2" Lg.
2 720-0263 Rubber Bumper
3 731-0473 Vinyl Grip
4 686-0002 Clutch Lever Ass’y.
5 720-0233 Handle Grip
6 710-0501 Hex Bolt 1/4-20 x 2" Lg.*
7 736-3090 Fl-Wash. 1/4" I.D.
8 710-1201 Hex Tap Scr. 1/4-20 x 1/2" Lg.
9 15093C Cable Bracket
10 712-0324 Lock Nut 1/4-20 Thd.
11 712-0429 Lock Nut 5/16-18 Thd.
12 712-0256 Hex Jam Nut 5/16-24 Thd.
13 736-0119 L-Wash. 5/16" I.D.*
14 746-0926 Clutch Control Cable
17 649-0018 Handle Ass’y.
19 710-3022 Hex Bolt 3/8-16 x 2.75
20 786-0146 Handle Channel–Frame
21 04764 Depth Stake
22 711-0653 Clevis Pin
23 714-0145 Hairpin Cotter
24 710-0376 Hex Bolt 5/16-18 x 1" Lg.*
25 710-0759 Hex Bolt 5/16-18 x 5/8" Lg.*
26 786-0011 L.H. Frame Half
27 786-0010 R.H. Frame Half
28 710-0607 Hex Tap. Scr. 5/16-18 x 1/2" Lg
29 750-0845 Spacer
30 710-1090 Hex Bolt 5/16-18 x 1-1/4" Lg.
31 714-3017 Cotter Pin
32 786-0012 Wheel Bracket
33 634-0013 Wheel–6"
34 738-0855 Axle–Wheel
35 720-0258 Hub Cap
36 786-0151A Belt Cover
37 710-0751 Hex Bolt 1/4-20 x .620" Lg.*
39 754-0216 V-Belt
40 756-0996 Pulley–Chain Case
45 756-0199 Flat Idler Pulley
47 712-0116 Hex Jam L-Nut 3/8-24 Thd.
49 784-0016 Idler Arm Ass’y.
51 756-0286 Engine Pulley
52 714-0122 Square Key 3/16" x .75" Lg.
53 786-0148A Tine Shield
54 736-0289 Washer–Bushing
57 686-0093A Chain Case Ass’y. Comp.
58 04922 R.H. Tine Blade
59 04923 L.H. Tine Blade
60 714-0149B Hairpin Cotter
61 04918 Adapter Ass’y.–Tine
62 711-0702 Clevis Pin
63 726-0306 Cable Tie–Plastic
65 736-0329 L-Wash. 1/4" I.D.*
66 750-0846 Spacer
67 — Engine
68 736-3050 Fl-Wash. .406 I.D.
69 710-0599 Tap Scr. 1/4-20 x 1/2" Lg.
70 710-0502A Hex Bolt 3/8-16
71 736-0258 Fl-Wash. 3/8" I.D. x 1" O.D.
72 712-0287 Hex Nut 1/4-20 Thd.*
73 710-0107 Hex Bolt 5/16-24 x .5" Lg.
74 04921 Tine Blade Ass’y. C omp.
75 712-0267 Hex Nut 5/16-18 Thd.*
77 736-0169 L-Wash. 3/8" I.D.*
78 710-0152 Hex Bolt 3/8-24 x 1" Lg.
79 786-0046 Belt Cover Bracket
80 784-0190 Handle Adj. Crank
81 736-0300 Fl-Wash. .385" I.D. x .87" O.D.
82 786-0153 Belt Cover—Rear
83 712-0431 Hex L-Nut 3/8-16 Thd.
84 712-0379 Hex Flange L-Nut 3/8-24 Thd.
85 784-0191 Retainer Bracket
86 710-3008 Hex Bolt 5/16-18 x .75" Lg.
87 736-0264 Fl-Wash. .330 I.D.
Ref.
No.
Part No. Part Description
