Yard Machines 532 - Page 15

15
Ref.
No.
Part Number Description
1.
681-0141 Front Wheel Bracket Assembly
2.
710-0116 Hex Cap Screw, 5/16-18 x 2.0
3.
710-0134 Carriage Screw, 1/4-20 x .625
4.
710-0578 Machine Screw, 1/4-20 x 1.5
5.
710-1007 Sems Screw, 3/8-16 x 1.5
6.
710-1174 Carriage Bolt, 5/16-18 x 2.0
7.
710-1205 Eye Bolt (Rope Guide), 1/4-20
8.
710-3013 Hex Cap Screw, 1/4-20 x .5
9.
710-3180 Hex Cap Screw, 5/16-18 x 1.75
10.
712-0287 Hex Nut, 1/4-20
11.
712-0324 Hex Lock Nut, 1/4-20
12.
712-0429 Hex Lock Nut, 5/16-18
13.
712-3020 Jam Lock Nut, 3/8-16
14.
720-0241 Wing Knob, 5/16-18
15.
720-0279 Wing Knob, 1/4-20
16.
726-0240 Cable Tie
17.
731-1931 Block Bushing, .515 x .62
18.
731-1935 Discharge Deflector Shield
19.
732-0369 Compression Spring, .55 x 1.37
20.
732-0867 LH Torsion Spring, .655
21.
736-0258 Flat Washer, .385 x 1.0 x .135
22.
736-0329 Lock Washer, 1/4
23.
736-0342 Flat Washer, .283 x .75 x .030
24.
736-0451 Saddle Washer, .320 x .93
25.
738-0481A Shoulder Screw, 3/8-16, .5 x 2.62
26.
746-1094 Depth Index Cable, 44.5”
27.
747-0976A Blade Control Bail
28.
747-0993 Cable Roller Rod
29.
749-1078 Lower Handle
30.
749-1225 Upper Handle
31.
756-0625 Cable Roller
32.
781-0741 Depth Index Bracket
33.
781-0742 Depth Index Lever
34.
781-0746 Discharge Deflector Keeper
35.
781-0747 Depth Cable Keeper
36.
631-0079A Edger Base Assembly
37.
750-1179 Sleeve Spacer, .520 x .860
38.
781-0783 Curb Wheel Adjuster Plate
39.
781-0781 Curb Wheel Back Plate
40.
746-1098 Control Cable w/ Clip, 31.75”
41.
734-1988 Bar Tread Wheel, 7 x 1.8
42.
734-1987 Bar Tread Wheel, 8 x 1.8
43.
681-0140 Curb Wheel Support Bracket
44.
710-1017 Truss Screw, 1/4-14 x .625
45.
710-1241 Hi-Lo Tap Screw, 1/4-15 x 1.0
46.
711-1171 Ferrule, 5/16-24 s .312
47.
711-1278 Curb Axle
48.
714-0104 Internal Cotter Pin
49.
720-0312 Height Adjuster Grip, 2.5”
50.
726-0100 Push Cap, 3/8
51.
726-0299 Push Cap, 1/2
52.
731-1932 Curb Support Roller
53.
732-0982 Height Adjuster Spring Lever
54.
736-0105 Bell Washer, .401 x .870 x .063
55.
736-0326 Flat Washer, .510 x 1.0 x .125
56.
738-0102 Shoulder Screw, 3/8-16, .49 x 1.4
57.
738-0507B Shoulder Screw, .50 x .434
58.
747-0991 Link Rod, 5/16-24
59.
781-0744 Curb Wheel Pivot Arm
Ref.
No.
Part Number Description
Handle / Frame Assembly
