Yard-Man 573 - Page 15

15
Model 573
Ref. No. Part No. Description
1. 747-0824 Control Handle
2. 710-1270 Oval C-Sunk Screw
3. 712-0324 Hex Lock Nut
4. 746-0883 Control Housing
5. 738-0878 Rear Axle
6. 749-0705A Upper Handle
7. 710-1205 Rope Guide
8. 710-1174 Carriage Bolt
9. 749-0928A Lower Handle
10. 720-0279 Wing Nut
11. 720-0284 Hand Knob
12. 714-0104 Hairpin Clip
13. 746-0555 Control Cable 55”
14. 750-0151 Spacer
15. 726-0240 Cable Tie
16. 17098 Hinge Clip
17. 731-0872A Trail Shield
18. 682-0139 Cutting Deck Assembly: 20”
19. 736-0105 Bell Washer
20. 720-0426 Knob: Height Adjustment
21. 732-0404 Lever: Spring
22. 734-2005A Front Wheel Assy. 8 x 2.125”
23. 736-0504 Wave Washer
24. 738-0102 Axle Bolt: Front
25. 731-1426 Hubcap: Radial Spoke, Yellow
26. 738-0507B Shoulder Bolt
27. 15262B Pivot Bar
28. 682-0518 Handle Bracket Assembly RH
682-0517 Handle Bracket Assembly LH
29. 736-0331 Bell Washer
30. 732-0731 Torsion Spring
31. 14578 Height Adjust. Assembly RH
14579 Height Adjust. Assembly LH*
32. 782-7006 Mounting Bracket
33. 736-0270 Bell Washer
34. 710-0599 Hex Washer Hd. TT Screw
35. 710-0654A TT Sems Screw
36. 731-1409 Chute Deflector
37. 682-7002 Mulching Plug Assembly
38. 712-0431 Hex Lock Nut
39. 15261A Height Adjustment Plate
41. 748-0376C Blade Adapter
753-0588 Blade Adapter Kit (for service)
42. 742-0740 20” Mulching Blade
43. 736-0524A Blade Bell Support
44. 710-1044 Hex Bolt
45. 747-0710 Hinge Pin
46. 736-0451 Saddle Washer
47. 712-0798 Lock Nut
48. 712-0328 Hex Nut 3/8-24
49. 712-3020 Lock Nut
50. 734-2043 Rear Wheel 14 x 2.125”
51. 736-3050 Flat Washer
52. 731-04123 Engine Shroud
53. 738-04032 Hex Bolt #10-32 x 0.30”
Ref. No. Part No. Description
NOTE: For painted parts, please refer to
the list of color codes below. Please add
the applicable color code, wherever
needed, to the part number to order a
replacement part. For instance, if a part
numbered 700-xxxx is painted Yard-Man
Green, the part number to order would be
700-xxxx-0665.
Yard-Man Green: 0665
Yard-Man Yellow: 0674
Powder Black: 0637
