Yard-Man YM26CS - Section 3: Adjusting the J-Handle; J-Handle Ergonomic Adjustment

9
SECTION 3: ADJUSTING THE J-HANDLE
4. Tighten the clamp screws evenly, until the J-handle is
secure.
3. While holding the unit in the operating position
(Fig. 3), position the J-handle to the location
that provides you the best grip.
Decal
ADJUSTING THE J-HANDLE
1. Loosen the four (4) screws holding the J-handle in
place (Fig. 1). Do not completely remove the screws.
(4) Screws
J-Handle
2. Slide the J-handle in or out until the arrow/white line
on the decal touches the clamp assembly (Fig. 2).
Fig. 1
Fig. 2
Fig. 3
