E25
PARTS LIST
Item Part No. Description
1 791-00057 Throttle Housing and Trigger Assembly (includes 2 & 3)
2 791-00058 Throttle Trigger
3 791-182690 Throttle Trigger Spring
4 791-182877 Throttle Cable Assembly
5 753-04236 Upper Drive Shaft Housing Assembly
6 791-610327 Harness Clip
7 791-180869 Deluxe D-Handle Assembly (includes 8-10)
8 791-181070 Screw
9 791-182167 Deluxe D-Handle
10 791-182168 Bottom Clamp
11 791-182928 EZ-Link™ Coupler (includes 12-15)
12 791-182057 Screw
13 791-181617 Bolt
14 791-181618 Adjustment Knob
15 791-181886 Nut
16 753-1212 Lower Drive Shaft Housing Assembly
17 791-181166 Lower Flexible Drive Shaft
18 791-153597 Lower Clamp Assembly (includes 19)
19 791-145569 Anti-Rotation Screw
20 791-181566 Gear Box Assembly
21 791-180547 Shield Mounting Hardware
22 791-180548 Shield and Blade Assembly
23 791-180553 Blade Assembly
24 791-181457 Outer Spool and Eyelet Assembly w/ Retainer
25 791-181458 Retainer
26 791-181561 Thrust Washer
27 753-04257 Slider
28 791-181459 Small Spring
29 791-181532 E-Clip
30 791-181531 Spring
31 791-181462 Plunger
32 791-181463 C-Clip
33 791-181464 Inner Reel
34 791-181465 Large Spring
35 791-181467 Foam Seal
36 791-181468 Bump Head Knob Assembly (includes 34 & 35)
37 791-182405 Switch Assembly
Optional Accessories
* 791-181460 Reel and Line Assembly
* 791-682075B Shoulder Strap Assembly
* Items Not Shown
1
13
14
15
16
1
9
7
6
8
10
11
12
5
3
2
20
17
22
18
25
19
21
23
28
26
27
4
29
33
31
30
35
32
34
36
24
37
BOOM AND TRIMMER PARTS -
MODEL YM75
2-CYCLE GAS TRIMMER
PPN 41ADY75C401
