FLOOR PANELS
2" (5,1 cm)
PARTS REQUIRED:
3/4" x 48" x 96"
(1,9 x 121,9 x 243,8 cm)
GAUGE BLOCK
GAA
Install next two panels and nal panel on frame, ush to the installed panels.
Use GAA gauge block to maintain 3/4” on oor joist.
Secure panels using 2" nails 6" apart on edges and 12" apart inside panel.
4
3
5
Cut one (1) panel in half to get two panels.These panels are cut so that all floor panels
are staggered.
Install panel ush to the outside edge of the oor frame and ush to the installed panel.
Use GAA gauge block to maintain 3/4” on oor joist.
Secure panel using 2” nails 6” apart on edges and 12” apart inside panel.
Block
Block
Block
6" (15,2 cm)
Flush
Flush
FlushFlush
12" (30,5 cm)
To Next Page
