PARTS REQUIRED:
BACK WALL PANELS
2" (5,1 cm)

3/8 x 48 x 84"
(1 x 121,9 x 213,4 cm )

12"
(30,5 cm)
6" (15,2 cm)
48"
(121,9 cm)
48"
(121,9 cm)
Flush Flush
Flush
Primed
side UP
3
Place 2nd and 3rd  panels on frame as shown and ush with installed panel.
Secure panel using 2" nails 6" apart along seam and 12" apart inside panel.
You have nished building your back wall.
FINISH
4
To draw panels tight
at seams angle nail.

GAUGE BLOCK
GAA
NOTE: Wall shown is a generic image.
1-1/2"
(3,8 cm)
