YARDMAX YD8105 User Manual

M10 × 25 × 2
6
M12 × 40 × 2
Figure 2e
Figure 2f
7. Install the mounting bracket base with two M10×30 bolts
and washers. (See Figure 2e)
8. Install the already assembled plow blade to the trackbarrow
as shown. (See Figure 2f)
M10 × 30 × 2
5
M12×40 (×2)M10×25 (×2)
17 mm
18 mm
30 mm
13 mm
11 mm
17 mm
18 mm
30 mm
13 mm
11 mm
3
M10×30 (×2)
Mounting Bracket Base
2
1
17 mm
18 mm
30 mm
13 mm
11 mm
10
Power Trackbarrow
»
Operator’s Manual
YD8105PM04 - 1804
Assembly of Optional Accessories
|
